Phoenix Contact 3209523 PT 2.5 BU Series Blue, 0.14 → 4mm², Single-Level, Push In Termination

Name: Phoenix Contact 3209523 PT 2.5 BU Series Blue, 0.14 → 4mm², Single-Level, Push In Termination
Brand: Phoenix Contact

Phoenix Contact

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nRail connector 2-wire 4 mm\u00B2 blue PT 2.5 BU 3209523\nPHOENIX CONTACT\nMPN : 3209523\nEAN: 4046356329798\nRated Current In: 24\nRated Voltage [V] 1: 800\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nNumber of terminals per level2\nConnection PositionTop / Top\nType of electrical connection 2Spring Clamp\nColourBlue\nNumber of Levels1\nRated Current In [A]24A\ncross section of the connected cable wire with sleeve tip [mm2] to2.5 mm\u00B2\nCross section of the connection cable without sleeve tip [mm2]2.5mm\u00B2\nCross section of the connected cable wire with sleeve tip [mm2]2.5mm\u00B2\nCross section of connected single wire cable [mm2]2.5mm\u00B2\nCross section of the connected cable wire with sleeve tip [mm2] from0.14 mm\u00B2\ncross section of the connected rope wire without sleeve tip [mm2] to2.5 mm\u00B2\nCross section of the connected rope wire without sleeve tip [m.
